1220x2440mm Modular Plastic Formwork Versatile Modular Concrete Formwork For Foundation And Column Molding

Brand Name : WKS

Certification : ROHS

Place of Origin : Hebei,China

MOQ : 50 piece

Price : US $55.00 - 70.00/ Square Meter

Payment Terms : T/T

Supply Ability : 1000 piece in 10 days

Delivery Time : 10-30 workday

Packaging Details : Bundled / Tied in bundles/Optimization of container loading

Product name : Modular Plastic Formwork

Maximum size : 1.2*0.6m

weight : 14kg/sqm

Operating temperature : -20℃to +80℃

Surface hardness : 94

Customize or not : Available in custom or standard sizes

Color : black / white

Are ㎡/pcs : 1.8000

Maximum billet thickness : 300mm

Density : 1.03g/cm³-1.28g/cm³

Reusability : Reusable up to 100+ times

Maximum load pressure : 60KN/sqm for wall & 80KN/sqm for column

Contact Now

1220x2440mm ABS Plastic Formwork Sheets 15mm Thick Reusable Shuttering
1220x2440mm ABS Plastic Formwork Sheets 15mm Thick Reusable Shuttering
Overview
ABS Plastic Formwork is a premium, high-strength construction formwork system engineered for demanding concrete forming applications. Made from industrial-grade Acrylonitrile Butadiene Styrene, it is the optimal choice for projects requiring superior impact resistance, exceptional surface finish, and extended service life. It effectively replaces traditional wood and steel formwork, offering a sustainable and cost-effective solution for walls, columns, beams, and slabs.
Features & Functions
  • Premium Durability: Offers outstanding toughness and impact resistance, outperforming standard PP formwork. It withstands heavy loads, repetitive use, and harsh site handling without cracking or warping.
  • Ultra-Smooth Finish: Engineered for a superior architectural finish, producing concrete surfaces that are exceptionally smooth, minimizing or eliminating the need for grinding and plastering.
  • Enhanced Weather Resistance: Features excellent resistance to UV rays, moisture, and a wide range of chemicals, ensuring stable performance in diverse and extreme climates, from intense sun to freezing temperatures.
  • Lightweight & Efficient: Significantly lighter than steel, it enables rapid installation and stripping with smaller crews, dramatically reducing labor costs and project timelines.
Key Specifications
  • Material: High-Impact, UV-Stabilized ABS Plastic
  • Standard Panel Size: 1200mm x 2400mm (Custom sizes available)
  • Panel Thickness: 12mm, 15mm, 18mm
  • Reuse Cycles: 80+ times under normal conditions
  • Temperature Range: -30°C to +85°C
  • Fire Rating: Self-extinguishing (UL94 V-0 rating achievable)
Competitive Advantages
  • Lowest Total Cost of Ownership: The highest reuse cycle in the plastic formwork category delivers the lowest per-pour cost, providing the best return on investment.
  • Unmatched Versatility & Finish: Ideal for high-value commercial and architectural projects where surface quality and dimensional accuracy are critical. Ensures a perfect finish every time.
  • All-Weather Reliability: Superior thermal stability prevents warping in heat and retains flexibility in cold, guaranteeing consistent performance and reducing project delays.
Features
Item Features
Materials ABS (Acrylonitrile Butadiene Styrene)
Density 1.03g/cm³-1.28g/cm³
Weight 14kg/sqm
Max Size 1.2*0.6m
Max Casting Slab Thickness 300mm
Maximum Load Pressure 60KN/sqm for wall & 80KN/sqm for column
Operation Temp -20℃ to +80℃
Surface Hardness 94
Specifications
Name Size (Length*Width*Height mm) Color Weight (KG) Material
Panel 1200*600*75 mm Black 10.1 ABS (Acrylonitrile Butadiene Styrene)
400*600*75 mm Black 3.7 ABS (Acrylonitrile Butadiene Styrene)
350*600*75 mm Black 3.4 ABS (Acrylonitrile Butadiene Styrene)
300*600*75 mm Black 2.7 ABS (Acrylonitrile Butadiene Styrene)
250*600*75 mm Black 2.5 ABS (Acrylonitrile Butadiene Styrene)
200*600*75 mm Black 2.2 ABS (Acrylonitrile Butadiene Styrene)
180*600*75 mm Black 2.1 ABS (Acrylonitrile Butadiene Styrene)
300*300*75 mm Black 1.4 ABS (Acrylonitrile Butadiene Styrene)
300*250*75 mm Black 1.3 ABS (Acrylonitrile Butadiene Styrene)
300*200*75 mm Black 1.25 ABS (Acrylonitrile Butadiene Styrene)
300*150*75 mm Black 0.7 ABS (Acrylonitrile Butadiene Styrene)
250*250*75 mm Black 1.13 ABS (Acrylonitrile Butadiene Styrene)
250*200*75 mm Black 0.9 ABS (Acrylonitrile Butadiene Styrene)
200*200*75 mm Black 0.8 ABS (Acrylonitrile Butadiene Styrene)
200*150*75 mm Black 0.6 ABS (Acrylonitrile Butadiene Styrene)
Outside Corner Panel 250*600*75 mm Black 2.85 ABS (Acrylonitrile Butadiene Styrene)
Internal Corner Panel 250*100*600*75 mm Black 3.5 ABS (Acrylonitrile Butadiene Styrene)
Top Angle Panel 250*250*100*75 mm Black 1.5 ABS (Acrylonitrile Butadiene Styrene)
Handle - White 0.1 PA (Polyamides)
1220x2440mm Modular Plastic Formwork Versatile Modular Concrete Formwork For Foundation And Column Molding
Frequently Asked Questions
Are you a trading company or a manufacturer?
  • Firstly, we are a subsidiary foreign trade company of a group company, mainly responsible for operating the export business of formwork and scaffolding products for the group company.
  • Secondly, our group company has two major production bases, specializing in the production and processing of formwork and scaffolding products for over 20 years.
How can I get a quotation?
  • If you are a simple concrete pouring project, such as walls, swimming pools, main structures, and basements, and you have your own engineer, you can directly provide us with a bill of materials, and we will provide you with a quotation according to the bill of materials.
  • If you are a concrete pouring project for apartments, residences, villas, etc., and need to use plastic formwork products as a whole, our professional consultants will communicate with you in detail. After you provide us with the engineering architectural drawings and structural drawings, our engineers will develop an application plan for you and provide you with a quotation based on the specific plan.
How long does it usually take to complete the plan and quotation after we provide the engineering architectural drawings and structural drawings?
  • Generally, it takes about 5-8 days to complete the specific plan and detailed quotation.
Can you provide free samples?
  • Yes, we can provide samples. You will need to pay for the shipping cost.
How long is the estimated delivery time after the contract is signed?
  • According to the complexity of the project, it usually takes 30-60 days to complete the stocking. We will estimate a more accurate delivery time for you during the planning and quotation process.
Is the plastic template prone to deformation?
  • If the construction environment where the project is located belongs to long-term high temperature, the increase in temperature of the concrete pouring project may cause slight deformation of the formwork. It is recommended to use all aluminum alloy formwork or steel frame wood formwork system in high temperature areas.
What are the defects of the plastic template system?
  • The load force is too small to complete the construction of large-sized concrete structures; Poor high temperature resistance, slight deformation may occur when used in high-temperature areas.
What is the payment method you require?
  • Payment <= 1,000 USD, 100% in advance.
  • Payment >= 10,000 USD, 30% T/T in advance, balance before shipment.
  • Or L/C.
